P6.66 Outdoor Rental Display

 Location: > Home >Products >
    P6.66 Outdoor Rental Display

Description:



Part Item Description
Module Pixel pitch 6.66mm
Pixel density 45000dots/sqm
Pixel configuration RGB
Brightness ≥7000cd/sqm
LED resource SMD3528
Module resolution 48×48=3600dots
Driving method 1/6scan
View angle Horizontal ≥160°(+10°/-10°)
View angle Vertical ≥120°(+10°/-10°)
Best viewing distance 6.66m~70m
Module dimension 320mm×160mm
Module flatness ≤0.2mm
Grey level 12bit
Cabinet Cabinet material Die-casting
Cabinet size 640mm×640mm×75mm
 Finished weight 10kg
 Color Silver (Cabinet and cover colors are selectable)
Flatness between cabinets < 0.2 mm
Installation Hanging or Standing
Load carring capacity ≥ 80 KG
Electrical parameter Serial frequency 30MHz
Fresh rate ≥960Hz
Input voltage 4.8~5.5V
Max current of module 2.5A
Max power consumption <1000W/sqm
MTBF ≥10,000hours
Lifespan 75,000~100,000hours
Failure rate <0.0002
Operation Operation environment Outdoor
Working temperature  -20~50°C
Working humidity 10%~90%RH
Store temperature 0~40°C
Store humidity 30%~60%RH
Items on a complete LED cabinet Modules 8pcs
Power supplier 1pc 5V80A GT-ENERGY
Power connector YZK, 2sets
Signal connector Xishang, 2sets
Receiving card RV801
HUB board 1pc
Package Flightcase  or honeycomb carton Selectable
